Interpupillary Distance
60 mm to 74 mm
Safety Class for Laser
Class 1
Palettes
Black Hot, White Hot, Red Hot, Fusion
Dimensions
229 x 148 x 80 mm / 9.0 x 5.8 x 3.1 in
Infrared Illuminator
Built-in 850nm Smart IR.Power and beam angle adjustment.
Distance Measurement
Laser Rangefinder: up to 1,000 m, ±1 m accuracy
Scene Mode
Jungle, Recognition
Video Recording
Yes
Audio Recording
Yes
Magnification
Thermal Channel - 4.5x - 20x / Optical Channel - 5.5x – 22x
Detector type
Thermal Detector - 12μm VOx Uncooled Focal Plane Array / Digital Sensor - 3840×2160, 1/88” Progressive Scan CMOS
FFC (Flat Field Correction)
Auto, Manual, External Correction
Highest Temperature Spot Tracking
Yes
Standby Mode
Yes
Refresh rate
50 Hz
Resolution
640 × 512
Laser Wavelength
905 nm
Detection Range (6' object)
1,800 m
Snapshot
Yes
Lens system
Thermal Channel - 50 mm; F1.0 / Optical Channel - 60 mm, F2.2
NETD
Less than 15 mK (25°C, F#=1.0)
Field of view (H × X)
Thermal Channel - 8.8 x 5.3 / Optical Channel - 6.9° × 4.1°
Diopter adjustment range
-5 to +3
Monitor
1920×1080, 0.49 inch, OLED, 50 FPS
Display
Day, Night, Auto
Storage
64 GB EMMC
Battery Type
Replaceable and Rechargeable Li-ion Battery Pack
Wi-Fi
Yes
Battery Life (Operating)
8.5 hours
Power supply
5 VDC/2 A, USB Type-C interface. Supports external power supply.
Operating Temperature Range
-20°C to 55°C (-4°F to 131°F)
Weight
0.83 kg / 1.82 lb
Protection Level
IP67 (Waterproof)
