AGM Taipan TM25-384 Thermal Monocular 25mm

AGM Taipan TM25-384 Thermal Monocular 384x288 / 12um (50Hz) 25mm w/Recording (3092451004TA21)



Authorized Dealer





AGM Taipan TM25-384 Thermal Monocular 25mm offers superior clarity with its 384x288 infrared detector and 1280x960 LCOS display. Enhanced features include highest temperature target tracking, distance measurement, and Wi-Fi hotspot. Ideal for patrolling, searching, hiking, and more, this thermal monocular ensures visibility in the dark.

AGM Taipan TM25-384 CHARACTERISTICS:



Detector type: Vanadium Oxide Uncooled Focal Plane Arrays

Refresh rate: 50 Hz

Resolution: 384x288

FOV: 17.5° × 13.1°

2.5x base mag



AGM Taipan TM25-384 FUNCTIONS:



AGM Taipan TM25-384 Distance Measurement:

The device realizes distance measurement function after marking the top and bottom of target, and input the target height.

AGM Taipan TM25-384 Hot Spot Mark:

The device detects and marks the hot spot of highest temperature.

AGM Taipan TM25-384 Mode Switch:

Device supports pallet switch and distance measurement.

AGM Taipan TM25-384 Storage:

Built-in memory module supports video recording/snapshot capturing.

AGM Taipan TM25-384 Digital Zoom:

Device supports 1×, 2×, 4×, and 8× digital zoom.

AGM Taipan TM25-384 Wi-Fi Hotspot:

Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.

AGM Taipan TM25-384 Features:

• 384×288 resolution, 12 μm, high sensitivity detector
• Adaptive AGC, DDE, 3D DNR
• 1280 × 960 resolution 0.4-inch LCOS display
• Built-in rechargeable Lithium battery
• More than 7.5 hours continuous running (with Wi-Fi hotspot function off)
• Wi-Fi hotspot
• Type-C interface
• 5-year warranty



AGM Taipan TM25-384 Specifications:

Interface

USB Type-C

Pixel Interval

12 μm

Multi Language menu

Yes

Drop Test Height

1.5 m (4.9 feet)

Detector type

Vanadium Oxide Uncooled Focal Plane Arrays

Response Waveband

8μm to 14μm

FFC (Flat Field Correction)

Auto, Manual, External Correction

Highest Temperature Spot Tracking

Yes

Standby Mode

Yes

Refresh rate

50 Hz

Aperture

F1.0

Resolution

384×288

Detection Range

1180 m

NETD

Less than 35 mk (@25°C), F#=1.0

Lens (focal length)

25 mm

Power

5 VDC/2 A, 1.5 W

Field of view (H × X)

10.5° × 7.9° (H × V)

Digital zoom

2×, 4×, 8×

Monitor

1280×960, 0.4 inch, LCOS

Imaging palettes

Black Hot, White Hot, Red Hot, Fusion

Storage

Built-in memory module (8 GB)

Record Video

On-board video recording

Capture Snapshot

Yes

Battery Type

Built-in rechargeable Lithium battery

Wi-Fi

Yes

CVBS Output

Yes (via USB)

Battery Operating Time

-20°C to 55°C (-4°F to 131°F)

Battery Capacity Display

Yes

Weight

300 g (0.69 lb)

Working Temperature/ Humidity

-20°C to 55°C (-4°F to 131°F)

Overall Dimensions

171 × 61 × 57 mm (6.73 × 2.4 × 2.2 in)

Protection Level

IP67



Included:

Lens Tissue

AC Power Adapter/Charger

Operators Manual

Protective Bag

Neck Belt

USB Cable
