ATN PS31-3HFW BNVD Gen 3 White Phosphor 40 FOV Night Vision Goggl Binocular 2200+ FOM

ATN PS31-3HFW BNVD Gen 3 White Phosphor 40 FOV Night Vision Goggl Binocular 2200+ FOM

SKU:NVGOPS3143HPW

Regular price $ 10,995.00
Regular price Sale price $ 10,995.00
Sale Sold out
Shipping calculated at checkout.

ATN PS31-3HWF BNVD Gen 3 White Phosphor 40 FOV Night Vision Goggles/Binoculars Grade A, Auto Gated, FOM 2200-2375 (NVGOPS3143HPW)



Authorized Dealer



Due to the nature of this item, please check with me for the lead time before ordering.



The PS-31 Binocular Night Vision Device (BNVD) is a compact, lightweight, dual tube goggle to replace the legacy PS-15. In a sea of dual tube night vision goggles, the PS-31 is one of the smallest and lightest units by far. The PS31s can be outfitted with various levels of high-performance US made Gen 3 image intensifier tubes. Working directly with U.S. Operators input, the PS-31 was designed to increase system resolution, significantly reduce head borne weight, improve system of center of gravity, provide additional operational utility, and improve overall operator situational awareness and adding a 50 deg FOV for maximum visibility in the field. These tubes are auto gain-capable, allowing the system to adjust the brightness of their image as situations on the ground dictate. The PS-31 BNVD has independently pivoting tube housings that allow the operator to run the goggle in a binocular or monocular configuration. Using two tubes at once allows the eyes to create depth perception and increases the ease in maneuvering terrain and obstacles as well as operating devices such as control panels and door knobs. However, monocular configurations allow for ease in transitioning between various lighting conditions that often occur on the battlefield and cause operators to switch between night vision and weapon-mounted optics. Another benefit to the pivoting tube housings is the ability to mount the “flatten” goggle against the front helmet surface when stowed. The ability to pivot the tube housings against the helmet surface creates an overall lower profile, increasing operator safety and equipment life.





ATN PS31-3HFW BNVD Gen 3 White Phosphor TECHNICAL SPECIFICATIONS



Generation - USA Gen 3, White Phosphor, Auto-Gated/Thin-Filmed High FOM 2200-2375

Resolution - 64-72 lp/mm

Magnification - 1 X

Lens System - f/1.18

Proshield Lens Coating - Yes

FOV - 40 °

Range of Focus - - 0.25 yard/m to infinity

Diopter Adjustment - -5 to +5

Automatic Brightness Control - Yes

Bright Light Cut-off - Yes

Infrared Illuminator - Yes (Built-in with flood lens)

IR Indicator - Yes (in FOV)

Low Battery Indicator - Yes (in FOV)

Power Supply - 1 x 3V (CR123)

Battery Life - 60 h – standard/ 300 h – with Battery Pack (optional)

Environmental Rating - IP65

Finish - Matte Black, Corrosion Resistant, Fibre re-enforces polycarbonate body

Operating Temperature - -59°F to 120°F / -51°C to 49°C

Storage Temperature - -59°F to 185°F / -51°C to 85°C

Dimensions - 4.4" x 4.15" x 3.4"/112 mm x 105 mm x 86 mm

Weight - 1.28 lbs / 0.58 kg

Country of Origin - USA

Available for Export - No

Warranty - 3 years



Whats in box



Instruction Manual

Lens Tissue

Soft Carrying Case

Helmet Mount

One Lithium Battery (CR123)



EXPORT RESTRICTION

Please review our ITAR / EAR COMPLIANCE - The International Traffic in Arms Regulations (ITAR) & Export Administration Regulations (EAR)
