Bering Optics Hogster Vibe 1.4-5.6x25mm Ultra-Compact Thermal Scope 384x288 50Hz w/Onboard Recording & WiFi (BE43325)
The HOGSTER VIBE™ VOx 384x288 Thermal Weapon Sight is specifically designed to cater to the advanced needs of feral hog hunters. Weighing just over half a pound, this compact sight is rated for .308 caliber and features a Quick-Detach (QD) mount that easily attaches to any rifle equipped with a Picatinny rail. Its small size also makes it ideal for handheld scanning.
Equipped with high-quality Germanium lenses and a cutting-edge Vanadium Oxide (VOx) thermal core, along with proprietary circuitry, the HOGSTER VIBE™ delivers outstanding thermal imaging. It features a user-friendly menu for quick customization without losing focus on the target, offering BDC and Crosshair reticles and White, Black, or Colored image polarization options.
Built to withstand moisture, debris, and impact, the Bering Optics Hogster Vibe 25mm Thermal Scope is suitable for use in all environments and lighting conditions, including challenging scenarios involving dust, haze, and smoke. The nitrogen-purged construction keeps it free from moisture and allows it to retain heat, making it highly reliable in extreme conditions and temperatures.
Bering Optics Hogster Vibe 25mm Features:
• Superior for hogs and predator control at medium range distances
• Switchable image polarity: White Hot / Black Hot / Red Hot / Colored Hot
• Picture-in-Picture function- 2X magnified image on the top of the display
• 8 reticle patterns including 3 BDC reticles with 4 color options for each pattern
• Automatic shatter based thermal VOx core with Auto- or Manual calibration
• Stradiametric Rangefinder function to estimate the distance to the targets of known size
• Manual control of the image sharpness and screen brightness
• Ability to save up to 4 groups of zeroing calibration data
• Option to power by rechargeable 3.7V rechargeable batteries
• A precise lens focusing mechanism
• 5V DC external power supply option via a Type C USB port
• Blind Pixel repair option
• Battery status indicator
• Standby mode
• 16Gb internal memory
• Built-in internal recording function
• Wi-Fi capable- allows media recording to the mobile device (Super Hogster App is required)
• Quick-Detach (QD) Picatinny mount (BE43325 / BE43335)
• LaRue Tactical® Quick-Detach (QD) lockable mount (BE43335L)
• Nitrogen purged
• Video Out
• 4 years warranty on parts and labor
Bering Optics Hogster Vibe 25mm Specifications
|
Product Modification
|
HOGSTER VIBE
|
|
Product SKU#
|
BE43325
|
BE43335 / BE43335L
|
|
Optical Magnification, x
|
1.4x
|
2.0x
|
|
Digital Multiplication, X
|
2X, 3X, 4X
|
|
Objective lens system
|
25mmF/1.1
|
35mmF/1.1
|
|
Angular FOV at 1.0x (horizontal x vertical), degree
|
14.9° x 11.2°
|
10.7° x 8°
|
|
Eye relief, mm
|
40
|
|
Focus range, m
|
1 to infinity
|
|
Diopter Adjustment, D
|
-5: +5
|
|
Reticle W/E adjustment value at a distance of 100m (110yds)
|
1.34"/3.4cm increment per pxl
|
0.96"/2.43cm increment per pxl
|
|
Core resolution, pxl
|
384x288
|
|
Pixel pitch, μm
|
17
|
|
Image refresh rate, Hz
|
50
|
|
Thermal Sensitivity (NETD), mK
|
≤ 40
|
|
Display type and resolution, pxl
|
LCOS 1280x960
|
|
Start-up time, min., sec.
|
20
|
|
Object type and size, approx., ft² / m²
|
Hog
7.5 / 0.7
|
Coyote
5.5 / 0.5
|
Hog
7.5 / 0.7
|
Coyote
5.5 / 0.5
|
|
Detection, approx., yds / m
|
600 /550
|
460 /420
|
800 /720
|
660/600
|
|
Recognition, approx., yds / m
|
225 /200
|
160 /145
|
300 /275
|
200 /185
|
|
Dimensions with QD mount, in / mm
|
7.0 x 2. 83 x 2.36 / 180x72x60
|
7.68 x 2. 83 x 2.36 / 195x72x60
|
|
Weight w/out batteries, approx., oz/g
|
16.44 / 466
|
17.14 / 486
|
|
Power supply
|
3V CR123 (two) or 3.7V rechargeable 16650 (two) or
5V Type C USB port
|
|
Estimated battery life with two Lithium 3V CR123, hour
|
4.0
|
|
Operating temperature, typical, °F/°С
|
4° to +122° / -15° to +50°
|
|
Water intrusion
|
IP66
|
|
Humidity, %
|
up to 98%
|
KIT INCLUDES
HOGSTER VIBE™ 384x288 Thermal Sight
Video-out or external power supply Type C USB cable
QD Weapon Mount
Two Lithium CR123 batteries
Front lens protective cap
Eye piece rubber eye guard
Soft Carrying Case
Lens Cleaning Cloth
Instruction manual
OPTIONAL ACCESSORIES
Focus Ring Cattail by ZRTS (BE80980) for HOGSTER VIBE with 35mm Lens (BE43335 / BE43335L)
Tactical Rubber Eye Guard (BE80030)
Extended Battery Cap (BE80008)
