Pulsar Merger DUO NXP50 Multispectral Thermal Binoculars 640

Pulsar Merger DUO NXP50 Multispectral Thermal Binoculars 640x480 50Hz 3x-24x (PL77455)

2-4 week lead time upon order

Thermal imaging binoculars are perfect for observation and spotting in difficult environments like dense forests, harsh weather, or expansive landscapes. Their dual eyepiece design allows for more natural and comfortable viewing with both eyes, reducing eye strain and enhancing focus. Though they resemble traditional daytime binoculars, their strength lies in advanced thermal technology. With options for high-definition thermal sensors and varying levels of sensitivity, users can select the ideal model based on their needs, whether they prioritize greater zoom or compact, portable design. For night hunting, multispectral devices stand out, offering both thermal and night vision capabilities, making them indispensable for spotting targets in the dark.

Pulsar’s Merger Duo NXP50, the brand's first multispectral binocular, sets a new standard in the field by combining thermal and digital channels. This powerful combination delivers superior detection, recognition, and identification capabilities for both day and night observation.

Key features of the Merger Duo NXP50 include:

• Thermal Channel: Offering exceptional thermal sensitivity, this mode excels in detecting objects regardless of weather or distance, making it highly effective for long-range observation.
• Full-HD Night Vision: With ultra-low-light performance, this channel reveals fine details, ensuring that users can clearly identify features of the observed object even in complete darkness.
• Picture-in-Picture Mode: This feature merges both the thermal and night vision channels, providing comprehensive situational awareness and ensuring no detail is missed.

With its combined digital night vision and thermal imaging capabilities, the Merger Duo NXP50 is an ideal tool for anyone needing high performance in total darkness or challenging environments.

Pulsar Merger DUO NXP50 Specifications:

Main

Sensor

640x480 pix. @ 17 µm (thermal) | CMOS 1920x1200 (digital)

Objective lens

F50/1.0 (thermal) | F50/1.4 (digital)

Magnification, x

3 – 24 (thermal) | 1.5 – 12 (digital)

Field of view (HxV), degrees / m@100m

12.4x9.3 / 21.8x16.4 (thermal channel on minimal magnification) | 21.1x16.3 / 16.4x12.3 (digital channel on minimal magnification)

IR Illuminator wavelength, nm

940 (invisible)

IR Optical power, mW

500

Detection range, m

1800 (thermal detection)

Sensor

Type

Uncooled, microbolometric (thermal) | Full-HD CMOS (digital)

Resolution, pixels

640x480 pix. @ 17 µm (thermal) | CMOS 1920x1200 (digital)

Pixel pitch, µm

17 (thermal)

NETD, mK

<25 (thermal)

Frame rate, Hz

50

Optics

Objective lens

F50/1.0 (thermal) | F50/1.4 (digital)

Magnification, x

3 – 24 (thermal) | 1.5 – 12 (digital)

Field of view (HxV), degrees / m @ 100 m

12.4x9.3 / 21.8x16.4 (thermal channel on minimal magnification) | 21.1x16.3 / 16.4x12.3 (digital channel on minimal magnification)

Eye relief, mm

12

Display

Type

AMOLED HD

Resolution, pixels

1280х960

Infrared Illuminator

Emitter

LED

IR wavelength, nm

940

IR Optical power, mW

500

Beam divergence, degree

≥ FOV

IR spot position adjustment

yes

Range Performance

Detection range, m

1800 (thermal)

Reticle

Click value, H/V, mm at 100 m

-

Click range, H/V, mm at 100 m

-

Number of preloaded reticles

-

Video Recorder

Video / photo resolution, pixel

1280х960

Video / photo format

.mp4 / .jpg

Built-in memory, GB

-

Wi-Fi

Wireless Protocol

Wi-Fi

Wireless Standard

IEEE 802.11 b/g/n/ac (WPA)

Frequency, GHz

2.4 / 5

Environmental Characteristics

Degree of protection, IP code (IEC60529)

IPХ7 (waterproof)

Operating temperature range, °С

-25 – +50

Connections and Compatibilities

Max. recoil power on rifled weapon (Eo), Joules

-

Shock resistance on the smooth-bore rifles, caliber

-

Compatible mounts

-

Supported Application

-

Power Supply

Output voltage, V

3.0 – 4.2

Battery type

Dual Li-Ion power system: APS 3 changeable battery (3.2 A·h) and built-in battery pack (4.0 A·h)

Capacity, mAh

3200 (external) + 4000 (internal)

Operating time on battery pack (at t=22°C), h *

7.5

External power supply, V

5V, 9V (USB Type-C Power Delivery)

Weight & Size

Body material

Magnesium alloy

Dimensions, mm

207x140x73

Weight, kg

1.2 (batteries included)

Factory 3-Year Warranty with 2-Year Extension upon registration for USA Market



Included in Package:

• Multispectral binoculars
• IR-Illuminator
• АPS3 Battery Pack
• APS battery charger
• Power adapter
• USB Type-C cable with USB Type-A adapter
• Carrying case with straps
• Neck strap
• Quick-Start guide
• Lens cloth
• Warranty card
• Tripod adapter
